STRYDE

SPECIFICATIONS

Capacity: 48 Quantum units
Interface: Ethernet
Power and Voltage: 1350W, 110 to 240 VAC
Operating Temperature: 0 ˚C to +40 ˚C
Storage Temperature: -15 ˚C to +50 ˚C

PHYSICAL

Size: 203.2 cm x 56.64 cm x 39.37 cm (80” x 22.3” x 15.5”)
Weight: 95.8 kg (211 lbs)

QC TOOL – QUANTUM
The QC Tool can quickly acquire information from deployed
Quantum via Bluetooth technology. It requires minimal user
interaction, allowing station QC and status information to be
collected efficiently while moving through the spread.

FEATURES

Android Operating System
High-performance all-in-one integrated GPS device
Ultra-rugged form factor
Integrated GPS (GPS/GLONASS/Galileo/BeiDou)
Internal rechargeable battery
Touchscreen 15.2 cm (6 inch) HD display
Data synchronization with iX1 software

SPECIFICATIONS

Operating temperature: –20 °C to +55 °C (–4 °F to +131 °F)
Storage Temperature: –40 °C to +70 °C (–40 °F to +158 °F)
Humidity: 0% to 95% (non-condensing)
Water: IP67, IEC 60529
Drop: 6 drops from 4.6 ft. (1.4 m)
Altitude: 15,000 ft
Size: 19.2 cm x 9.1 cm x 1.45 cm (7.5” x 3.5” x 0.5”)
Weight: 380 g (13.4 oz), with extended battery

SPM STANDARD RACK
FEATURES

Standard offering of Seismic Processor Module (SPM) for
G3i® HD, Hawk® and Quantum®
High-end multi-processor workstation technology
Redundant high-capacity internal hard disk drives
Support for up to four external monitors
SEG output data formats (SEG-D v2.1, v3.0 or SEG-Y Rev 0)

SPECIFICATIONS* RACK

System Capacity:
300,000 channels (G3i HD)
60,000 channels (Quantum)
20,000 channels (Hawk)
Power and Voltage: 1650 W, 90 to 240 VAC
Size: 54.1 cm x 62 cm x 75.4 cm (21.3” W x 24.4” H x 29.7” D)
Weight: 186 kg (410 lbs)
Operating Temperature: 0 °C to +45 °C**
Storage Temperature: -10 °C to +60 °C
* INOVA reserves the right to change specifications without notice
** Operating at extreme temperatures for an extended period of time may cause equipment malfunction

SPM (Seismic Processor Module)
Processors: Intel Xeon (minimum of 80 cores)
Memory: 384 GB
Internal Storage: 24 TB
Connectivity: 1 or 10 GbE Ethernet, USB 3.0
Other Interface Support: mSAS, Fiber Channel

UPS (Uninterruptible Power Supply)
Power Input: 80–265 VAC
Power Frequency: 47–440 Hz
Capacity: 3000 VA
